Rig Name/ Type Pasargad 100/ Independent 3 leg Jack up
Design CP 300
Water Depth 300 ft.
Drilling Depth 30000 ft.
Built Year 2013
Leg Length 427 ft.
Class Notations A1 Self-Elevating MODU
Max Variable Drilling Load 7716 KIPS
Accommodation 105 Persons
Derrick 35Ft*40Ft Base
Draw works JC 90DB. 4 * 720 Kw Ac Motor
Top Drive TDS 8 SA NOV. 750 Ton. 1150 HP
Rotary Table CNPC / ZP495,” 49 ½”
MUD Pump 3*BOMCO/ F-1600HL,Triplex
Rig Name/ Type Pasargad 200/ Independent 3 leg Jack up
Design Super M2
Water Depth 300 ft.
Drilling Depth 30000 ft.
Built Year 2019
Leg Length 411 ft.
Class Notations ACSXA1 Self-Elevating MODU
Max Variable Drilling Load 6784 KIPS
Accommodation 110 Persons
Derrick 35Ft*40Ft Base
Draw works TSC Power: 2x1500HP
Top Drive TDS 8 SA NOV. 750 Ton. 1150 HP
Rotary Table One 49-1/2″ , Max Continuous torpue:35000Ib-ft
MUD Pump 3XTSC 2000 triplex single acting triplex mud pump
